Nichicon KA 4700uf – 16v

Description:

Aluminium Electrolytic Capacitors – Radial Leaded 16V 4700uF -55 to 105C

Unit Price: 5.30
Payment
We Ship Worldwide

67 in stock

Working on restoration? Find Recap Kit

Description

Nichicon KA Series 4700uf – 16v

Manufacturer: Nichicon
Product: Audio Grade Electrolytic Capacitors
Termination Style: Radial
Capacitance: 4700 uF
Voltage Rating DC: 16 VDC
Tolerance: 20 %
Ripple Current: 1480 mA
Minimum Operating Temperature: – 55 C
Maximum Operating Temperature: + 105 C
Diameter: 12.5 mm
Length: 35.5 mm
Life: 2000 Hour
Series: UKA

Reviews

There are no reviews yet.

Be the first to review “Nichicon KA 4700uf – 16v”

Product Review

Nichicon KA Series audio capacitors

Nichicon KA Series Audio Capacitor was designed as a higher-grade 105C capacitor capable
of achieving higher sound quality in audio devices than Nichicon
standard 105C-resistant KT Series. KA Series capacitors from Nichicon
are constructed with select materials to create superior acoustic sound
and are compliant to the RoHS directive (2002/95/EC).

Features

  • Capacitance range: 22 to 22000uF
  • Rated voltage range: 6.3 to 50V
  • Category temperature range: -55C to +105C
Download Datasheet Nichicon KA Series Datasheet
